S-2000 Hingeway

The most unique opening available, the Hingeway offers less intrusion into the interior, less lost space when open, and more of a canopy to the exterior.  Flush Mountable and awe-inspiring, there's no other opening on the market quite like it.

​

The S-2000 model can be constructed into custom doors, windows or wall systems.  The steel frame is designed to withstand 30 pfs high wind loads with minimal deflection.

​

This design is something that cannot be copied by cable and strap doors or hydraulic doors and uses our unique counterweight balance system to lift the panels smoothly and quietly.

3232WentwoodDriveDallasTexas75225(24) copy.jpg

The most unique opening available, the Hingeway offers less intrusion into the interior, less lost space when open, and more of a canopy to the exterior.  Flush Mountable and awe inspiring, there's no other opening on the market quite like it.

Features & Options

  • Max Width: 30 FT

  • Max Height: 20 FT

  • Steel Frame w/Aluminum Glass Capture

  • REDD Alert Obstruction Sensing

  • Photo Eyes

  • Touch Screen Wall Controller

  • Counterweight Counter-Balance

  • Operation: Motorized or Manual

  • Glass Options: 1/4" & 1" IGU

  • Cladding Options: Up to 2" & 15 lbs per SQF

  • Finish: Powder Coat

  • Flush Mount Available: YES

  • Remote Weight Options: YES

  • High-Wind Load Areas: YES

  • Compatible With Screens:  Limited

  • NFRC Rated: YES

Design & Specify
